Spiraflex® Black Lay-Flat Super-Duty Hose
Application:
Spiraflex Black is a lay-flat, heavy-duty water discharge and washdown hose that combines the lightweight, compact features of PVC with the durability and abrasion resistance of conventional construction. This hose features a unique one-piece, through-the-weave construction and attains its working pressure from a synthetic woven textile. Resists mildew/rot and requires no drying time. Its excellent durability is derived from a high-tensile rubber compound, which completely encases the jacket. Applications include irrigation, washdown, dewatering, coal preparation and utility plants; gas drilling; jetting and pump discharge; storage tank cleaning and sewer cleaning.
Construction:
Tube/Cover: Nitrile/PVC compound. Both tube and cover are simultaneously extruded to obtain maximum bending.
Reinforcement: Through-the-weave fabric
Temperature Range: -36°F to 178°F (-37°C to 81°C)
Packaging: Coiled
Branding: No branding
Non-Stock/Sizes: Contact your Continental ContiTech representative for special production run minimum requirements.
Order Codes: Contact Customer Service for ordering details.
| ID | Nom. OD | Max. WP | Weight | ||||
|---|---|---|---|---|---|---|---|
| in. | mm | in. | mm | psi | MPa | lbs./ft. | kg/m |
| 1-1/2 | 38.09 | 1.58 | 40.13 | 300 | 1.72 | 0.26 | 0.38 |
| 2 | 50.80 | 2.08 | 52.83 | 250 | 1.72 | 0.36 | 0.54 |
| 2-1/2 | 63.50 | 2.58 | 65.53 | 250 | 1.72 | 0.46 | 0.68 |
| 3 | 76.19 | 3.10 | 78.74 | 230 | 1.72 | 0.52 | 0.77 |
| 4 | 101.6 | 4.10 | 104.14 | 200 | 1.38 | 0.72 | 1.07 |
| 6 | 152.39 | 6.13 | 155.70 | 150 | 1.03 | 1.25 | 1.86 |
| 8 | 203.20 | 8.16 | 207.26 | 150 | 1.03 | 1.70 | 2.53 |
