Black Softwall

Application:
For the discharge of dry bulk cement from tank truck and in-plant service.

Construction:

Tube:
1/8″ (static dissipating/static conductive) Black ChemiTuf™ synthetic rubber. Available in 1/8″, 3/16″, and 1/4″ tube gauges.

Cover: Black SBR with white spiral stripe (wrapped impression)

Reinforcement: Spiral-plied synthetic fabric

Temperature Range: -25°F to 180°F (-32°C to 82°C)

Packaging: 100' lengths, coiled and polywrapped

Branding: Continental ContiTech Black Softwall

Couplings: Contact fitting manufacturer for proper fitting recommendation and coupling procedure. Use Continental ContiTech Insta-Lock™ Cam & Groove Fittings with this product. See the “Couplings Systems” section of this website for available Insta-Lock products.

Non-Stock/Sizes: For special production run minimum requirements, contact Customer Service.

Order Codes:
549-152 (1/8″ tube gauge 50psi) / 549-149 (3/16″ tube gauge) / 549-148 (1/4″ tube gauge) / 549-795 (with Survivor Compound: 4X100 – 1/4) / 549-790 (with Survivor Compound: 4X100 – 1/8) / 549-804 (with Survivor Compound: 4X 00 – 3/16)

549-152 (1/8″ tube gauge 50 psi)

SAP # Dia. ID OD Max. WP Weight
1/8″ Survivor mm mm mm psi kg/m
20019306 3 76.1 86.3 50 1.05
20019309 20665783 4 102.1 112.3 50 1.38
20046192 4.5 114.6 125.4 50 1.64
20019315 20677559 5 127.4 138.2 50 1.82
20019319 6 152.7 163.9 50 2.25



549-149 (3/16″ tube gauge 75 psi)

SAP # Dia. ID OD Max. WP Weight
3/16″ Survivor mm mm mm psi kg/m
20019281 20673663 4 102.1 116.2 75 1.92
20029627 4.5 114.6 129.0 75 2.21
20109496 5 127.4 141.8 75 2.44
20468267 5.5 140.1 154.5 75 2.67
20446687 6 152.7 167.7 75 3.01



549-148 (1/4″ tube gauge 50 psi)

SAP # Dia. ID OD Max. WP Weight
1/4″ Survivor mm mm mm psi kg/m
20019277 20639327 4 102.1 118.7 50 2.29
20311113 4.5 114.6 131.8 50 2.65
20019279 5 127.4 145.0 50 3
20019280 6 152.7 170.3 50 3.56
